VOLTAGE MONITOR 400VAC
Voltage Monitor:
- Compact modular modules in the Electro D series of control and timing devices make it simple to integrate them into distribution boards or standard panels.
- They align with ordinary tiny circuit breakers (MCBs) and attach straight onto DIN rail.
- To generate exact switching levels, the voltage monitor is constructed with the newest microcontroller with a high-resolution analogue converter.
- The device is perfect for all voltage monitoring applications because it can be ordered in a broad range of AC and DC voltages.
- Unmonitored fault conditions are prevented via the latch facility.
- The front-mounted dials allow for adjustments to the trip level, hysteresis, and delay function.
- A front sliding switch allows you to choose between over and under monitoring.
Features:
- Latching facility that is optional.
- Relay with 10A SPDT output.
- 4 Selectable delays at the front face.
- Variable voltage level on the front face.
- Mountable on a modular 35.5mm DIN rail.
- Adjustable hysteresis on the front face 5–50%.
- Analog microprocessor with high resolution.
- Selectable front face Above/Below observation.
- Relay and power supply ON LED indicator.
Specifications:
- DESCRIPTION: Voltage monitor device
- CONTACT: 10A SPDT
- DELAYS: No delay, startup delay 10 second,180 second recovery delay, reaction delay 10 second
- INPUT: Pin 5 & 9
- RANGES: 4, 40, 400 VAC/DC
- HYSTERESIS: 5 - 50%
- RATED VOLTAGE: 250V
- MECHANICAL LIFE: 10x106 cycles
- PROTECTION INDEX IP: IP 20
- OPERATING TEMPERATURE: -10 to + 50°C
- STORAGE TEMPERATURE: -50 to + 85°C
- DIMENSIONS (MM): (H) 92 x (W) 36 x (D) 64
| Brand | Electrodev |
|---|
