VSPC BASE 1CL FG EX

ZAR 794.09
Out of stock
SKU
8951810000

Description:

  • A base component for a single floating-ground-powered paired cable.
  • A connection is made between the mounting rail and the inbuilt sparkover gap upon base element installation.
  • A high impedance connection is formed between the earth potential and the ground of the protective switch in the protective plug through this sparkover gap.
  • Mechanical coding of the protected plug's base element based on the rated voltage and switching type.
  • Suitable for ATEX applications.
  • The initial insertion of a protected plug codes the base unit.
  • Mechanical coding of the protected plug's base element based on the rated voltage and switching type.
  • All terminals can be marked.

Specifications:

  • Version: Surge protection, Flange-mounted housing.
  • Depth: 69 mm.
  • Height: 90 mm.
  • Width: 17.8 mm.
  • Storage temperature: -40 °C...80 °C.
  • Operating temperature: -40 °C...70 °C.
  • Humidity: 5...96 %.
  • Color: Light Blue.
  • Design: Terminal, miscellaneous.
  • No Optical function display.
  • Protection degree: IP20.
  • Rail: TS 35, TS 35 x 7.5.
  • Segment: Measurement - Monitoring – Setting.
  • UL 94 flammability rating: V-0.
More Information
Brand Weidmuller
