Specifications dimensions and weights:

• Depth: 69 mm.
• Depth (inches): 2.717 inch.
• Height: 98 mm.
• Height (inches): 3.858 inch.
• Width: 17.8 mm.
• Width (inches): 0.701 inch.
• Net weight: 74 g.

Temperatures:

• Storage temperature: -40 °C - 80 °C.
• Operating temperature: -40 °C - 70.
• Humidity: 5 - 96 %.

Environmental Product Compliance:

• REACH SVHC: Lead 7439-92-1.
• SCIP: 5047b468-d57a-4a1c-8363-2ff1629067e4.

Rated data UL:

• Certificate No. (UL): E311081.
• UL certificate: UL 497b Certificate.

Connection data, remote alert:

• Connection type: Screw connection.
• Cross-section for connected wire, solid core, maximum: 1.5 mm².
• Cross-section for connected wire, solid core, minimum: 0.5 mm².
• Maximum torque: 0.2 Nm.
• Stripping length: 6 mm.

CSA protection data:

• Gas group C: IIB.
• Gas group D: IIA.
• Gas groups A, B: IIC.
• Input current, maximum II: 300 mA.
• Internal inductance, maximum LI: 0 µH.

General data:

• Colour: black.
• Design: Terminal, miscellaneous.
• Optical function display: No.
• Protection degree: IP20.
• Rail: TS 35.
• TS 35 x 7.5.
• Segment: Measurement - Monitoring - Setting.
• UL 94 flammability rating: V-0.
• Version: Flange-mounted housing.
• Insulation coordination acc.to EN 50178:
• Pollution severity: 2.
• Surge voltage category: III.

Rated data IEC / EN:

• Rated current IN: 10 A.
• Signalling contact: UN 250 V AC 0.1 A 1CO at VSPC R with VSPC control unit.
• Standards: IEC 61643-21, IEC 62305, DIN EN 60079-0.2009, DIN EN 60079-11: 2007, DIN EN 60079-26: 2007, DIN EN 61241-11: 2006.
• Voltage type: AC/DC.
• Further details of approvals:
• GOST certificate: GOST-Zertifikat.

Connection data:

• Stripping length: 7 mm.
• Type of connection: Screw connection.
• Stripping length, rated connection: 7 mm.
• Tightening torque, minimum: 0.5 Nm.
• Tightening torque, maximum: 0.8 Nm.
• Clamping range, minimum: 0.5 mm².
• Clamping range, maximum: 4 mm².
• Wire cross-section, solid, minimum: 0.5 mm².
• Wire cross-section, solid, maximum: 4 mm².
• Wire connection cross section, finely stranded, maximum: 2.5 mm².
• Conductor cross-section, flexible, AEH (DIN 46228-1), minimum: 0.5 mm².
• Conductor cross-section, flexible, AEH (DIN 46228-1), maximum: 2.5 mm².
• Connection cross-section, stranded, minimum: 0.5 mm².
• Connection cross-section, stranded, maximum: 2.5 mm².
• Blade size: 0.6 x 3.5 mm.

Ratings IECEx/ATEX/cUL:

• cUL certificate: cUL Certificate.
