Wireless Converter (2.4G TO RS-485 / 422 / 232)
A-3450 Wireless Data Converter:
- Sight distance credible transmission distance is up to 100m
- Offer byte-oriented transparent data adaptable to various user protocols
- Can be applied to manifold communication combination methods like point to point, point to multi-point and multi-point to point.
- Automatically filtrate fake data generated in air, can transmit longer data frames.
- High efficiency forward error correction channel coding technology, anti-jamming data.
- 2.4GHz ISM frequency range, need not apply for frequency pint.
- Equipped with 50 ohm SMA antenna pedestal, offer manifold antenna options.
- Meanwhile offer RS-232/RS-485/RS-422 level interface
- Effective speed 300~115200bps.
Specifications:
- Operation Voltage: 10~30VDC/24VAC
- Supports Max device: Maximum of 256 devices (Without repeater)
- Frequency range: 2400 – 2483.5 MHz
- Operation temperature: -20°C to +75 °C
- Storage temperature: -25 °C to +80 °C
- Installation: 35 mm DIN rail or Flush mounting
- Connection: Removable 13-pin Terminal Block ( For RS-422 / 485 / 232 )
- RF Module's Groups: 0~65535
- RF Module's ID: 0~65535
- RF Module's TX Power: 0~6
- RF Module's Channel: 0~200
- RF Module's Data Rate: 250K
- Dimension (W x H x D mm): 76.4*118.2*40.7 mm
| Brand | Yottacontrol |
|---|
