General details:

• Class of isolation: E.
• Up to 0.72 kV is the maximum operating voltage.
• 50 Hz is the nominal frequency (others upon request).
• Ith = 60 x In is the nominal thermal short-time current.
• FS 5 is the over-current limiting factor up to a nominal current of 1500 A.
• MBS AG current transformers completely comply with VBG 4, IEC 61869/1+2, DIN 42600, and DIN VDE 0414/1.
• Primary wound current transformers with class 1 (5A secondary).
• Main wound current transformers, WSK 30.
