ZK4800-8524-0028 Motor connection cable
highly flexible, drag-chain suitable cable with 5 million bending cycles, max. 240 m/min, max. 30 m/s², min. bending radius = 97 mm (7 x OD), max. drag-chain length horizontal 20 m, vertical 5 m, (4 x 2.5 mm² + (2 x 1 mm²) + (2 x AWG22)). The cable is UL and CSA listed.
Length: 28.00 mm
Head A
Installation size: M23
Connector type: plug
Contact type: female
Number of positions (face): Power: 3+PE, Signal: 5
Wire termination: crimp connection
Body color: metal
Head B
Installation size: Pitch dimension 10.16 mm
Connector type: plug
Contact type: female
Number of positions (face): 4-pin
Wire termination: Clamping yoke connection
Max. wire cross-section: AWG22 ... AWG4 (0.2 mm² ... 16 mm²)
Body color: black, similar to RAL 9011
Head C
Installation size: Pitch dimension 3.50 mm
Connector type: plug
Contact type: female
Number of positions (face): 5-pin
Wire termination: Clamping yoke connection
Max. wire cross-section: AWG28 ... AWG14 (0.2 mm² ... 1.5 mm²)
Body color: black, similar to RAL 9011
Meterware
Cross-section (power): 2.50 mm² (approx. AWG14)
Cross-section (signal): AWG22 (approx. 0.34 mm²)
Use: drag-chain suitable
Material jacket: TPU (thermoplastic polyurethane)
Outer cable diameter: 13.9 mm ± 0.4 mm (0.5472" ± 0.0157")
Jacket color: orange
| SKU | ZK4800-8524-0028 |
|---|
