Temperatures:

• Storage temperature: -25 °C - 55 °C.

Environmental Product Compliance:

• REACH SVHC: /.

Material data:

• Material: Wemid.
• Colour: red.
• UL 94 flammability rating: V-0.

Additional technical data:

• Explosion-tested version: Yes.
• Type of fixing: Plugged.
• Type of mounting: Direct mounting.

Cross-connector:

• Number of cross-connected terminals: 5.

Dimensions:

• Pitch in mm (P): 5.1 mm.

General:

• Number of poles: 5.

Rating data:

• Rated current: 24 A.

Important note:

• Product information:
• Due to stability and temperature reasons, It is only possible to break out 60% of contact elements.
• The usage of cross connectors reduces the rated voltage to 400V.
• The voltage reduced to 25V if cut cross connection with blank cut edges are used.
