Benchtop LCR Meters, UT622A: Handheld LCR Meters (10kHz, 0.1%)
SKU: UT622A
Out of stock
* Online sales only
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
The UT622A Handheld LCR Meter is a high-precision, portable component tester that is ideal for use in laboratories, production lines, maintenance sites, and electronic component inspection.
It has a 2.8-inch TFT LCD, numerous test frequencies ranging from 100 Hz to 10 kHz, automatic LCR identification, and adjustable test signal levels.
The meter enables three- and five-terminal testing, as well as Kelvin test lead expansion for more precise measurements.
Remaining stock can still be purchased. We can quote on an alternative or replacement product.
View recommended replacementRequest a backorder quote. We will confirm price and lead time before payment.
Buy currently uses Select Automation shop pricing and checkout.
Features:
Maximum test frequency of 10 kHz.
Maximum basic accuracy of 0.1%.
Measures:
Inductance (L).
Capacitance (C).
Resistance (R).
Impedance (Z).
ESR.
Dissipation factor (D).
Quality factor (Q).
Phase angle (θ).
Auto LCR component identification.
Test frequencies: 100 Hz, 120 Hz, 1 kHz and 10 kHz.
Selectable test signal levels: 0.1 Vrms, 0.3 Vrms and 1 Vrms.
100 Ω output impedance.
Three-terminal test jacks.
Five-terminal test sockets.
Supports Kelvin test lead expansion.
Fast, medium and slow measurement speeds.
Measurement rates up to 20 readings/s.
Auto and hold ranging modes.
Series and parallel equivalent circuit modes.
Open/short circuit correction.
Tolerance mode for component sorting.
Tolerance range of 1%–20%.
PASS/FAIL LED indication.
Recording mode for average, maximum, minimum and number of readings.
Mini-USB connectivity.
2.8-inch TFT LCD, 320 × 240 pixels.
Rechargeable 3.7 V, 1800 mAh lithium-polymer battery.
Specifications:
Product Type: Handheld LCR Meter.
Maximum Test Frequency: 10 kHz.
Accuracy: 0.1%.
Display Count: 99,999.
Minimum Resolution: 0.0001.
Inductance (L): 0.001 µH–9999.9 H.
Capacitance (C): 0.001 pF–99.999 mF.
Impedance / Resistance (Z/R): 0.0001 Ω–99.999 MΩ.
ESR: 0.01 m Ω–999.99 Ω
Dissipation Factor (D): 0.0001–9.9999.
Quality Factor (Q): 0.0001–99999.
Phase Angle (θ): -179.9° to 179.9°.
Test Frequencies: 100 Hz / 120 Hz / 1 kHz / 10 kHz.
Test Signal Levels: 0.1 Vrms / 0.3 Vrms / 1 Vrms.
Output Impedance: 100 Ω.
Measurement Parameters: Primary: L/C/R/Z; Secondary: D/Q/θ/ESR.
Auto LCR: Yes.
Test Terminals: Three-terminal jacks / five-terminal sockets.
Test Rate: Fast: 20 readings/s; Medium: 5 readings/s; Slow: 2 readings/s.
Ranging Mode: Auto / Hold.
Tolerance Range: 1%–20%.
Equivalent Circuit Mode: Series / Parallel.
Correction: Open / Short circuit.
Tolerance Indicator: PASS: green / FAIL: red.
Communication Interface: Mini-USB.
Display: 2.8-inch TFT LCD, 320 × 240.
Battery: 3.7 V, 1800 mAh rechargeable lithium-polymer.
Product Dimensions: 90 × 190 × 44 mm.
