CLI C 02-3 GE/SW / MP, 1.3 - 3mm, 3 x 3.4mm
SKU: 0252111742
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Pricing available on request
CLI C 02-3 (GE/SW / MP):
CLI C conductor markers are used to mark disconnected conductors.
Conductor cross-sections between 0.5 mm² and a maximum of 70 mm² can be labelled in four different sizes.
The markers are already printed and ready to use.
Individual labelling can be achieved by combining the individual markers.
Closed markers are reliable and can be mounted on disconnected lines.
A unique flexible bellow profile ensures a broad application range.
Fitting is quick and straightforward, requiring no effort.
Labelling is made simple with matching accessories.
Permanent, higher quality labelling.
High contrast for optimal legibility.
Buy currently uses Select Automation shop pricing and checkout.
Specifications dimensions and weights:
Depth: 3.5 mm.
Depth (inches): 0.138 inch.
Height: 3 mm.
Height (inches): 0.118 inch.
Width: 3.4 mm.
Width (inches): 0.134 inch.
Net weight: 0.04 g.
Temperatures:
Operating temperature range: -30 - 80 °C.
General data:
Colour: Yellow.
Colour of printing: Black.
Halogen: Yes.
Material: PVC, soft, without Cadmium.
Material colour according to resistance code: 4.
Number of markers per combination: 1 Component part = Conductor and cable markers.
Number of markers per packaging unit: Form of supply: Component part.
Operating temperature range: -30 - 80 °C.
Operating temperature range, max.: 80 °C.
Operating temperature range, min.: -30 °C.
Orientation of print: horizontal.
Printed characters: Symbols .
Printing: /.
Printing method: hot embossing.
Recommended industries: Process, Machinery.
Type of printing: Standard.
UL 94 flammability rating: V-0.
Version: Multipack.
Width: 3.4 mm.
Conductor and cable markers:
Conductor cross-section, max.: 1.5 mm².
Conductor cross-section, min.: 0.2 mm².
Conductor O.D.: 1.3 - 3 mm.
Conductor O.D., max.: 3 mm.
Conductor O.D., min.: 1.3 mm.
Cross-section for connected wire: 0.2 - 1.5 mm².
Halogen: Yes.
