IEC 12 A Miniature Contactor 12A, 230V 50/60Hz, 2 N.O. / 2 N.C. Main
SKU: 100-K12KF200
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Features:
Mini contactors.
Uniform panel mounting dimensions.
Panel mounting or mounting on 35 mm DIN Rail.
Made of environmentally friendly materials.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Auxiliary Contact configuration: None, 2N.O./2N.C. Poles.
Contactor Size: 12A.
Terminal Type: Screw terminal.
Mechanical:
Number of normally open contacts as main contact: 2.
Number of normally closed contacts as main contact: 2.
Electrical:
Voltage type for actuating: AC.
Rated control supply voltage at AC 50Hz: 230V.
Rated control supply voltage at AC 60Hz: 230V.
Rated control supply voltage at DC: 0V.
Type of electrical connection of main circuit: Screw connection.
Optional overload relays: None.
Main current circuit resistance: 2.2mΩ.
Auxiliary contact configuration: No auxiliary contact.
Environmental:
Ambient temperature: storage: -55° to 80°C (-67° to 176°F).
