IEC 16 A Reversing Contactor 16A, Line Side, 24V DC (w/Elec. Coil), 1 N.O. 1 N.C.
SKU: 104-C16EJ22
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Features:
Panel mounting or mounting on 35 mm DIN rail.
AC or DC coil control.
Reversible coil terminals (line or load side).
Common accessories.
Made of environmentally friendly materials.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Electrical:
Voltage type for actuating: DC.
Rated control supply voltage at DC: 24V.
Current Max: 97A.
Main circuit resistance: 2.7mΩ.
Coil Voltage: 24V DC with electronic coil.
Contacts: 3 Power poles with internal NO or NC auxiliary contact or 4 power poles (9 – 23A), Optional front-or side mounted 1 – 2 or 4 – pole external contactor block.
Function: Reversing contactor.
Rated coil frequency: AC 50/60Hz, DC.
Construction:
Optional overload relays: Electronic or bimetallic.
Mechanical:
Coil Termination: Line side connection.
Type of electrical connection of main circuit: Screw connection.
Environmental:
Auxiliary Contacts: 1NO, 1NC.
Ambient temperature: Storage: -55° to 80°C (-67° to 176°F).
