IEC 43 A Reversing Contactor 43A, Line Side, 24V 50/60Hz, 1 N.O. 1 N.C.
SKU: 104-C43KJ22
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Features:
Panel mounting or mounting on 35 mm DIN rail.
AC or DC coil control.
Reversible coil terminals (line or load side).
Common accessories.
Made of environmentally friendly materials.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Coil Code: 24V 50/60Hz.
Maximum Ampere Rating: 43A.
Electrical:
Voltage type for actuating: AC.
Current Max: 97A.
Rated control supply voltage at AC 50/60Hz: 24V.
Contacts: 3 Power poles with internal NO or NC auxiliary contact or 4 power poles (9 – 23A), Optional front-or side mounted 1 – 2 or 4 – pole external contactor block.
Function: Reversing contactor.
Rated coil frequency: AC 50/60Hz, DC.
Mechanical:
Coil Termination: Line side connection.
Type of electrical connection of main circuit: screw connection.
Construction:
Optional overload relays: Electronic or bimetallic.
Environmental:
Ambient temperature: Storage: -55° to 80°C (-67° to 176°F).
