Suction cup complete, VAS-100-1/4-PUR-B
SKU: 1396098
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Specifications
• Suction cups with connector VAS-...-SI-B/PUR-B
• Height compensator for suction cup 3.5 mm
• Nominal size 4 mm
• Suction cup diameter 100 mm
• Suction cup volume 33.5 cm³
• Effective suction diameter 90.5 mm
• Position of connection Top
• Mounting position optional
• Symbol 00991485
• Suction cup shape Round, flat
• Operating pressure -0.095 MPa ... 0 MPa
• Operating pressure -0.95 bar ... 0 bar
• Operating pressure -13.775 psi ... 0 psi
• Nominal operating pressure -0.07 MPa
• Nominal operating pressure -0.7 bar
• Nominal operating pressure -10.15 psi
• Operating medium Atmospheric air based on ISO 8573-1:2010 [7:-:-]
• Material suction cup PUR
Buy currently uses Select Automation shop pricing and checkout.
Suction cup with connection VAS, VASB
• The VAS(B) series is the right solution for transporting workpieces with a wide range of weights, surfaces and shapes.
• Sturdy and reliable
• Suction cups with fixed connecting thread
• 11 suction cup diameters
• Round suction cup, bellows
• Vacuum connection on top, on side
• Screw-in thread
