ACT20P-PRO DCDC II-P (Push In)
SKU: 1481960000
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Pricing available on request
Description:
The ACT20P-PRO DCDC II-P is a versatile analogue isolating amplifier intended for precise signal conversion and galvanic isolation.
It accepts both current and voltage input/output signals and includes a wide-range power supply, DIP switch or display-based programming, and three-way isolation for added safety and versatility in industrial settings.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Universal input/output: current or voltage
Power supply: 24–230 V AC/DC ±20%
Configuration: DIP switch or via display and pushbuttons
Display: Green dot-matrix with ticker text
Isolation: 3-way (input/output/supply)
Mounting: TS 35 DIN rail
Protection class: IP20
Weight and Dimensions:
Width: 12.5 mm
Height: 127.1 mm
Depth: 113.7 mm
Net weight: 130 g
Environmental Conditions:
Operating temperature: -20°C to +60°C
Storage temperature: up to +60°C
Humidity: 0–95% (non-condensing)
Operating altitude: ≤ 2000 m
Electrical Characteristics:
Input voltage range: ±40 mV to ±300 V
Input current range: ±0.1 mA to +100 mA
Output voltage: 0 to +10 V (adjustable)
Output current: 0 to +20 mA (configurable)
Load impedance (voltage): ≥ 1 kΩ
Load impedance (current): ≤ 600 Ω
Accuracy: <0.05% of measuring range
Step response time: ≤ 50 µs
Power consumption: ≤ 2.3 W
Safety & Compliance:
Rated voltage: 600 V
Impulse withstand voltage: 5 kV
EMC standard: EN 61326-1
Surge category: II
Pollution degree: 2
RoHS compliant with exemptions (7a, 7cI)
REACH SVHC: Lead (7439-92-1)
SIL: Not applicable
MTBF: 76 years
