CLI C 02-3 GE/SW Ä CD
SKU: 1568241056
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
CLI C 02-3 GE/SW Ä CD:
CLI C conductor markers are used to mark disconnected conductors.
Conductor cross-sections between 0.5 mm² and a maximum of 70 mm² can be labeled in four different sizes.
The markers are already printed and ready to use.
Buy currently uses Select Automation shop pricing and checkout.
Dimensions and weights:
Depth: 3.5 mm.
Depth (inches): 0.138 inch.
Height: 3 mm.
Height (inches): 0.118 inch.
Width: 3.4 mm.
Width (inches): 0.134 inch.
Net weight: 0.06 g.
Temperatures:
Operating temperature range: -30...80 °C.
Environmental Product Compliance:
REACH SVHC: /.
General data:
Colour: yellow.
Colour of printing: black.
Halogen: Yes.
Insulation cross-section, max.: 3.
Material: PVC, soft, without Cadmium.
Material colour according to resistance code: 4.
Number of markers per combination: 1 Reel = Conductor and cable markers.
Number of markers per packaging unit:
Form of supply: Reel.
Operating temperature range: -30...80 °C.
Operating temperature range, max.: 80 °C.
Operating temperature range, min.: -30 °C.
Orientation of print: horizontal.
Printed characters: Upper-case letters.
Printing: Ä.
Printing method: hot-embossing.
Recommended industries: Process, Machinery.
UL 94 flammability rating: V-0.
Version: CD.
Width: 3.4 mm.
Conductor and cable markers:
Conductor cross-section, max.: 1.5 mm².
Conductor cross-section, min.: 0.2 mm².
Conductor O.D.: 1.3 - 3 mm.
Conductor O.D., max.: 3 mm.
Conductor O.D., min.: 1.3 mm.
Cross-section for connected wire: 0.2 - 1.5 mm².
Halogen: Yes.
