Compact cylinder, AEVUZ-32-20-P-A

Specifications • Compact cylinder AEVU/AEVUZ, Single-acting, basic version • Stroke 20 mm • Piston diameter 32 mm • Cushioning Elastic cushioning rings/plates at both ends • Mounting position optional • Mode of operation Single-acting, Pulling • Piston-rod end Female thread • Design Piston, Piston rod • Position detection Via proximity switch • Symbol 00991204 • Variants Piston rod at one end • Operating pressure 0.08 MPa ... 1 MPa • Operating pressure 0.8 bar ... 10 bar • Operating pressure 11.6 psi ... 145 psi • Operating medium Compressed air to ISO 8573-1:2010 [7:4:4] • Theoretical force at 0.6 MPa (6 bar, 87 psi), advance stroke 382 N
