Proportional directional control valve, MPYE-5-1/4-420-B

Specifications • Proportional directional control valve MPYE • Nominal size 8 mm • Type of actuation Electric • Sealing principle Hard • Mounting position optional • Design Piston gate valve • Type of reset Magnetic spring • Safety instructions Safety position MPYE: if the power supply cable is blocked, the valve assumes the closed mid-position. • Type of piloting Direct • Flow direction Non-reversible • Symbol 00995308 • Valve function 5/3 closed • Pneumatic connection, port 1 G1/4 • Standard nominal flow rate (standardised to DIN 1343) 1400 l/min • Operational voltage range DC 17 V - 30 V
