Hand slide valve, VBOH-32-G34
SKU: 1629664
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Specifications
• Hand slide valve VBOH
• Valve function 3/2 double solenoid
• Pneumatic connection, port 1 G3/4
• Pneumatic connection, port 2 G3/4
• Type of actuation Manual
• Type of mounting In-line installation, Screw-in
• Standard nominal flow rate (standardised to DIN 1343) 7691 l/min
• Nominal size 19.3 mm
• Operating pressure -0.095 MPa ... 1.2 MPa
• Operating pressure -0.95 bar ... 12 bar
• Ambient temperature -10 °C ... 80 °C
• Material housing Anodised wrought aluminium alloy
• Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
• Grid dimension 57.5 mm
Buy currently uses Select Automation shop pricing and checkout.
Hand slide valve VBOH
• Elegant, non-overlapping shut-off valve for high flow rate and operating pressure.
• Used as a shut-off function for pressurising and exhausting compressed air systems, for example upstream of service units, for air guns and also for exhausting pneumatic cylinders
• Non-overlapping, so no pressure losses when switching
• Minimal installation effort
