ControlLogix 4 Slots Chassis
SKU: 1756-A4
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
The 1756-A4 is a compact four-slot chassis for the ControlLogix platform that is appropriate for small-scale or distributed automation applications.
It supports up to three ControlLogix modules and has one slot dedicated for a power supply, making it ideal for installations with limited space or modest I/O requirements.
Despite its compact footprint, the chassis supports all ControlLogix capabilities, including high-speed backplane connectivity, hot-swapping, and modular scaling.
Its sturdy aluminium chassis and various mounting choices make it suited for a variety of industrial applications, including control panels and distant I/O stations.
Whether you're developing a pilot system or deploying a small control node, the 1756-A4 provides dependable performance in a space-saving package.
Buy currently uses Select Automation shop pricing and checkout.
Mechanical & Physical:
Total Slots: 4 (1 for power supply, 3 for modules).
Dimensions:
Width: 228 mm (8.98 in).
Height: 145 mm (5.71 in).
Depth: 145 mm (5.71 in).
Weight: Approx. 1.2 kg (2.6 lb).
Mounting Options: Panel or DIN rail.
Backplane Type: Passive backplane for ControlLogix modules.
Backplane Current Capacity:
1.2V DC: 1.5 A max per slot.
3.3V DC: 4.0 A max per slot.
5.1V DC: 6.0 A max per slot (15.0 A total).
24V DC: 2.8 A max per slot.
Power & Thermal:
Power Consumption: ~1.0 W.
Thermal Dissipation: ~3.4 BTU/hr.
Environmental Ratings:
Operating Temperature: 0°C to +60°C.
Storage Temperature: –40°C to +85°C.
Humidity: 5% to 95%, non-condensing.
Shock Resistance: 30g.
Vibration Resistance: 10–500 Hz, 5g.
