ControlLogix Energy Storage Module-CAP
SKU: 1756-ESMCAP
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
The 1756-ESMCAP is a capacitor-based energy storage module that works with ControlLogix 5570 controllers (1756-L7x series).
It replaces typical lithium batteries by offering a maintenance-free option for preserving volatile memory during power outages or shutdowns.
This preserves vital data, such as tag values, diagnostics, and system status, without the need for battery replacement.
Unlike battery assemblies, the ESMCAP recharges quickly and provides long-term durability, making it perfect for industrial situations that require high uptime and minimum maintenance.
It fits directly into the controller housing and is essential for effective operation of L7x controllers.
Buy currently uses Select Automation shop pricing and checkout.
Functional Role:
Type: Capacitor-based energy storage module.
Purpose: Retains volatile memory during power loss.
Compatibility:
Required for 1756-L7x controllers (e.g., L71, L72, L73, L74, L75).
Not compatible with L6x or earlier series.
Mounting: Installs directly into the controller housing.
Electrical Characteristics:
Energy Storage: Solid-state capacitor.
Recharge Time: Typically, less than 30 minutes.
Discharge Duration: Sufficient to retain memory during brief outages or shutdowns.
Maintenance: No replacement required under normal operating conditions.
Environmental Ratings:
Operating Temperature: 0°C to +60°C.
Storage Temperature: –40°C to +85°C.
Humidity: 5% to 95%, non-condensing.
Shock Resistance: 30g.
Vibration Resistance: 10–500 Hz, 2g.
