ControlLogix 32 Pt 12/24V DC D/I Module
SKU: 1756-IB32
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
The 1756-IB32 is a high-density digital input module intended for use with ControlLogix systems.
It has 32 distinct input channels that accept 12/24V DC signals, making it perfect for monitoring a variety of industrial equipment like sensors, switches, and pushbuttons.
This module is designed to provide efficient data collecting, reliable performance, and flexible integration into demanding automation environments.
With its compact size and dependable input handling, it's ideal for control panels where space and signal density are crucial.
The 10-30V DC input range is compatible with both 12V and 24V systems.
Provides reverse polarity protection and strengthened insulation for increased safety.
Individual inputs are not isolated from one another.
Designed to be mounted in ControlLogix racks.
Compatible with ControlNet and other Rockwell Automation networks, allowing for smooth connection.
Ideal for scalable control systems, whether upgrading or starting from scratch.
Buy currently uses Select Automation shop pricing and checkout.
Electrical Specifications:
Input Channels: 32 digital inputs.
Input Type: DC sink/source.
Voltage Range: 10–30V DC.
Nominal Voltage: 12/24V DC.
Input Current: 5–15 mA per point.
Input Delay: ~1 ms typical.
Isolation:
Group-to-group: 250V continuous.
No isolation between individual inputs.
Power Requirements:
Backplane Current Draw:
5V DC: 470 mA.
24V DC: 250 mA.
Power Dissipation: ~5.5 W.
Environmental Ratings:
Operating Temperature: 0°C to 60°C (32°F to 140°F).
Storage Temperature: –40°C to 85°C (–40°F to 185°F).
Humidity: 5% to 95%, non-condensing.
Shock Resistance: 30g operational, 50g non-operational.
Vibration Resistance: 10–500 Hz, 5g.
