ControlLogix 16 Point Digital Input
SKU: 1756-IM16IK
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
The 1756-IM16IK is a 16-channel AC digital input module built for the ControlLogix-XT platform, which is used in harsh industrial applications.
It monitors 120V AC signals from field devices such as sensors, switches, and relays, making it perfect for harsh environments in the manufacturing, utility, and process industries.
This module has a conformal coating to protect against moisture, dust, and corrosive chemicals, assuring dependable operation in severe environments.
It allows hot-swapping, has LED indications for each channel, and effortlessly interacts with ControlLogix systems for efficient diagnostics and control.
With strong environmental certifications and consistent AC signal identification, the 1756-IM16IK is a reliable solution for high-reliability digital input in challenging environments.
Buy currently uses Select Automation shop pricing and checkout.
Electrical Specifications:
Input Channels: 16 digital inputs.
Input Voltage Range: 79–132V AC.
Input Frequency: 47–63 Hz.
Input Current: 6 mA @ 120V AC.
Input Delay (On/Off): 20 ms typical.
Input Type: AC (sink/source compatible).
Status Indicators: Individual channel LEDs.
Module & Installation:
Module Type: Digital input.
Terminal Block: Requires 36-pin RTB (Removable Terminal Block).
Hot-Swappable: Yes.
Conformal Coating: Yes (XT-rated for corrosive and humid environments).
Backplane Current Draw:
120 mA @ 5.1V DC.
100 mA @ 24V DC.
Environmental Ratings:
Operating Temperature: –25°C to +70°C.
Storage Temperature: –40°C to +85°C.
Humidity: 5% to 95%, non-condensing.
Shock Resistance: 30g.
Vibration Resistance: 10–500 Hz, 5g.
