ControlLogix 8 Point RTD/Thermocouple In
SKU: 1756-IRT8IK
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
The 1756-IRT8IK is a conformally coated temperature input module for the ControlLogix-XT platform, with eight individually customizable channels that accommodate RTD and thermocouple sensors.
It is intended for high-precision temperature monitoring in tough industrial conditions containing moisture, dust, and corrosive substances.
Each channel can be configured independently to accept a wide range of RTD kinds (such as PT100 and PT1000) or thermocouple types (J, K, T, E, R, S, B, N), making it perfect for complicated systems that require mixed sensor inputs.
With 24-bit resolution, extensive diagnostics, and features such as wire-off detection, sensor offset compensation, and notch filtering, this module offers dependable and precise temperature measurement.
The conformal coating increases longevity, while easy connection with ControlLogix systems enables quick configuration and real-time monitoring.
Buy currently uses Select Automation shop pricing and checkout.
Electrical & Signal Specifications:
Channels: 8 individually configurable inputs.
Sensor Types Supported:
RTD: PT100, PT1000, Nickel, Copper.
Thermocouple: J, K, T, E, R, S, B, N.
Other: Ohms and millivolt inputs.
Resolution: 24-bit.
RTD Resistance Ranges:
1–500 Ω.
2–1000 Ω.
4–2000 Ω.
8–4000 Ω.
Conversion Time: Fast acquisition with notch and digital filtering.
Diagnostics:
Wire-off detection.
Overrange/under range alerts.
Sensor offset correction.
Auto-ranging.
Environmental Ratings:
Conformal Coating: Yes (XT-rated for corrosive/humid environments).
Operating Temperature: –25°C to +70°C.
Storage Temperature: –40°C to +85°C.
Humidity: 5% to 95%, non-condensing.
Shock Resistance: 30g.
Vibration Resistance: 10–500 Hz, 5g.
Power & Installation:
Backplane Current Draw:
250 mA @ 5.1V DC.
100 mA @ 24V DC.
Power Dissipation: 3.5 W.
Mounting: ControlLogix chassis.
Terminal Block: Requires 36-pin RTB (Removable Terminal Block).
Hot-Swappable: Yes.
