GuardLogix 5580 Controller
SKU: 1756-L82ES
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
A dual-purpose controller from the GuardLogix 5580 family, the 1756-L82ES combines normal control and safety control into one unit.
It has 5 MB of regular memory and 2.5 MB of safety memory, allowing it to do both standard automation duties and safety-critical procedures simultaneously.
This controller supports Integrated Motion via EtherNet/IP, which allows for synchronized multi-axis motion control while ensuring safety compliance.
It has a 1 Gb Ethernet port for fast data transfer and a USB 2.0 port for local programming and diagnostics.
A 2 GB Secure Digital (SD) card comes pre-installed for non-volatile storage of user programs and tag data.
The 1756-L82ES complies with stringent safety requirements, including SIL CL3 (IEC 61508) and PL(e), Category 4 (ISO 13849-1), making it appropriate for use in robotics, packing, material handling, and other safety-critical situations.
It also has a 4-character alphanumeric display with real-time status updates.
Buy currently uses Select Automation shop pricing and checkout.
Memory & Processing:
Standard memory: 5 MB.
Safety memory: 2.5 MB.
Non-volatile storage: Pre-installed 2 GB SD card (1784-SD2).
Status display: 4-character alphanumeric LED for diagnostics.
Communication & Connectivity:
EtherNet/IP port: 1 × RJ-45, 1 Gb/s embedded Ethernet.
USB port: 1 × USB 2.0 (for temporary local programming).
Supported EtherNet/IP devices: Up to 175 nodes.
Integrated Motion over EtherNet/IP: Supported for multi-axis motion control.
Safety & Compliance:
Safety standards:
SIL CL3 (IEC 61508).
PL(e), Category 4 (ISO 13849-1).
Dual memory partitions: Isolated standard and safety logic.
Firmware security: Digitally signed and encrypted.
GuardLogix compatibility: Yes – supports safety-rated I/O and motion.
Physical & Environmental:
Mounting: Standard ControlLogix chassis slot.
Operating temperature: –20°C to 60°C.
Conformal coating option: Available (suffix “K”) for harsh environments.
Certifications: UL, CSA, CE, and hazardous location ratings.
