GuardLogix 5580 Controller
SKU: 1756-L83ES
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
The 1756-L83ES is a high-performance GuardLogix 5580 safety controller that integrates normal and safety control on a single platform.
Designed for demanding industrial applications, it provides quick processing, a huge memory capacity, and integrated motion over EtherNet/IP.
This controller is perfect for systems that require both high-speed automation and certified functional safety, such as those found in the automotive, packaging, and processing industries.
It has dual Gigabit Ethernet connections with Device-Level Ring (DLR) support for network redundancy and is programmed with Studio 5000 Logix Designer, which allows for unified construction of standard and safety logic.
To achieve safety redundancy, the 1756-L83ES must be linked with a 1756-L8SP Safety Partner module, guaranteeing that safety tasks are executed synchronously.
Buy currently uses Select Automation shop pricing and checkout.
Memory & Processing:
Standard Memory: 10 MB.
Safety Memory: 5 MB.
I/O Memory: 0.98 MB.
SD Card Support: 1 GB pre-installed (expandable to 2 GB).
Display: 4-character alphanumeric LED display.
Communication & Connectivity:
EtherNet/IP Ports: 1 × embedded Gigabit Ethernet port.
DLR Support: Yes (Device-Level Ring for network redundancy).
USB Port: 1 × USB 2.0 (Type B).
EtherNet/IP Devices Supported: Up to 250.
Network Connections:
256 EtherNet/IP connections.
128 TCP connections.
Safety & Control:
Safety Ratings:
SIL 3 (IEC 61508).
PLe, Category 4 (ISO 13849-1).
Integrated Safety Logic: Supports GuardLogix safety instructions.
Safety Partner Required: Must be paired with 1756-L8SP for safety redundancy.
Physical & Environmental:
Form Factor: Standard ControlLogix chassis module.
Operating Temperature: 0°C to +60°C.
Storage Temperature: –40°C to +85°C.
Humidity: 5% to 95%, non-condensing.
Shock Resistance: 30g.
Vibration Resistance: 10–500 Hz, 5g.
