ControlLogix 3 Axis SERCOS Servo Module
SKU: 1756-M03SE
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
The 1756-M03SE is a high-speed servo control module designed for use with ControlLogix systems, allowing for precise motion control over SERCOS (Serial Real-time Communication System) fibre optic networks.
It can support up to three axes of coordinated motion, making it perfect for applications including packaging, robotics, material handling, and CNC machinery.
This module interfaces with the Kinetix 6000 and other SERCOS-compatible drives, offering deterministic control and fast synchronization.
It works perfectly with Studio 5000 Logix Designer, enabling for unified programming of motion and logic controls.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Motion Axes Supported: 3.
Communication Protocol: SERCOS (fibre-optic ring).
Compatible Drives: Kinetix 6000, other SERCOS drives.
Control Type: Coordinated multi-axis servo control.
Programming Software: Studio 5000 Logix Designer.
Backplane Current Draw:
1.2 A @ 5.1 VDC.
3 mA @ 24 VDC.
Slot Requirement: Occupies 1 slot in a 1756 chassis.
Fiber Ports: 2 × SERCOS ports (for ring topology).
Motion Features:
Electronic gearing.
Camming.
Interpolation.
Position, velocity, and torque control.
Diagnostics: Integrated LED indicators and software-based status monitoring.
Environmental Ratings:
Operating Temperature: 0°C to +60°C.
Storage Temperature: –40°C to +85°C.
Humidity: 5% to 95%, non-condensing.
Shock Resistance: 30g.
Vibration Resistance: 10–500 Hz, 2g.
