      ControlLogix 16 Point D/O Module

      SKU: 1756-OA16I

      Out of stock

      Availability: Out of Stock

      Short Description
      Description: The 1756-OA16I is a 16-point isolated AC digital output module for the ControlLogix system, perfect for switching high-voltage AC loads like relays, solenoids, and motor starters. Each output channel is electrically separated, offering superior protection against electrical noise, transient surges, and cross-channel interference—particularly useful in high-noise industrial situations. This module covers a wide AC voltage range (74-265V AC) and can supply up to 2 amps per point, making it suitable for a variety of industrial applications. It has LED indicators for each channel that provide real-time status feedback, and its hot-swappable architecture enables for maintenance without requiring system downtime. The 1756-OA16I, designed for dependability and safety, is an excellent solution for demanding control systems that require individual channel isolation and high-current switching capacity.
      1756-OA16I
      Alternative image 1
      Electrical Specifications: Output Type: AC digital output (individually isolated channels). Number of Outputs: 16 channels. Voltage Range: 74–265V AC. Nominal Voltage: 120/240V AC. Current Rating: Up to 2 A per output. Minimum Load Current: 10 mA per point. Isolation: Channel-to-channel and channel-to-backplane. Surge Protection: Integrated for transient suppression. Output Delay: Typically, less than 1 ms (on/off). Environmental Ratings: Operating Temperature: 0°C to 60°C (32°F to 140°F). Storage Temperature: –40°C to 85°C. Humidity: 5% to 95%, non-condensing. Shock Resistance: 30g. Vibration Resistance: 10–500 Hz, 5g. Mechanical & Integration: Platform: ControlLogix chassis based I/O. Connection Type: Requires RTB (Removable Terminal Block) or 1492 IFM. Hot-Swappable: Yes. Status Indicators: Individual LEDs per output channel. Certifications: UL, CE, CSA.
