ControlLogix 16 Point D/O Module
SKU: 1756-OG16
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
The 1756-OG16 is a 16-point digital DC output module intended for use with ControlLogix® systems.
It generates TTL (Transistor-Transistor Logic) source outputs at 5V DC, making it excellent for high-speed, low-voltage digital control systems.
Each output channel is set to Low = True, which means a logical "0" enables the output.
This module is ideal for powering external devices such as logic-level actuators, LEDs, and relays in industrial automation settings because of its quick switching speeds and minimal signal delay.
Its compact form, high environmental tolerance, and interoperability with conventional ControlLogix chassis and terminal blocks make it a dependable choice for engineers developing scalable and responsive control solutions.
Output type: TTL digital source (Low = True).
Voltage range: 4.5 to 5.5 volts DC.
Channels: sixteen outputs.
Maximum current per channel: 24 mA.
Fast switching: from off to on in 450 µs and back to off in 700 µs.
Shock and vibration resistant: Designed for industrial applications.
Compatible Terminal Blocks: 1756-TBNH and 1756-TBSH.
Buy currently uses Select Automation shop pricing and checkout.
Output Configuration:
Type: Digital DC Output (TTL logic level).
Channels: 16 outputs.
Logic Level: TTL (Transistor-Transistor Logic), Low = True.
Voltage Range: 4.5V to 5.5V DC.
Nominal Voltage: 5V DC.
Max Output Current per Point: 24 mA @ 60°C.
Max Total Module Current: 384 mA @ 60°C.
Electrical Performance:
Signal Delay:
OFF to ON: 450 µs.
ON to OFF: 700 µs.
Leakage Current (OFF State): 0.1 mA per output.
ON-State Voltage Drop: 0.4V max.
Isolation Voltage: 50V continuous (channel-to-backplane).
Power & Thermal:
Backplane Current Draw:
210 mA @ 5.1V DC.
2 mA @ 24V DC.
Power Dissipation: 1.5 W max.
Thermal Dissipation: 5.2 BTU/hr @ 60°C.
Environmental Ratings:
Operating Temperature: 0°C to 60°C (32°F to 140°F).
Humidity: 5% to 95% non-condensing.
Shock Rating: 30G operational.
Vibration Resistance: 2.0G @ 10–500 Hz.
