ControlLogix 36 Pin Spring TRM Block
SKU: 1756-TBS6H
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
The 1756-TBS6H is a 36-pin spring-clamp removable terminal block (RTB) that is intended for use with ControlLogix I/O modules.
It offers a secure, tool-free connection for field wiring, enabling quick installation and maintenance.
The spring-clamp design provides consistent contact pressure and is excellent for settings with vibration or frequent wiring changes.
Connection type: Spring clamp (no screwdriver required).
Pin count is 36.
Wire Sizes: 22-14 AWG solid, 22-16 AWG stranded.
Hot swappable: Yes (with compatible modules).
Compatible Modules: Digital and analogue I/O modules with 36-pin RTBs.
Housing Options: Supports both regular (1756-TBH) and deep (1756-TBE) housings.
Buy currently uses Select Automation shop pricing and checkout.
General Features:
36-pin removable terminal block (RTB).
Spring-clamp connection (tool-free wire insertion).
Designed for ControlLogix I/O modules.
Supports hot swapping when used with compatible modules.
Terminal identification markings included.
Electrical & Mechanical Specs:
Wire size range:
Solid: 22–14 AWG.
Stranded: 22–16 AWG.
No torque requirement (spring clamp design).
Mounts directly to front of I/O module.
Compatible housings:
Standard: 1756-TBH.
Deep: 1756-TBE.
Red: 1756-TBES.
Material: Industrial-grade thermoplastic.
Colour: Typically, black or grey.
Environmental Ratings:
Operating temperature: 0°C to +60°C.
Storage temperature: –40°C to +85°C.
Humidity: 5% to 95%, non-condensing.
Shock resistance: 30g.
Vibration resistance: 10–500 Hz, 5g.
