CompactLogix 16 Pt 120VAC D/I Module
SKU: 1769-IA16K
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
The 1769-IA16K is a 16-point digital input module for Allen-Bradley CompactLogix 1769 systems, including conformal coating for added protection in demanding situations.
It can detect 120V AC signals and is suited for industrial automation applications.
Input channels: 16 digital inputs.
Voltage range is 79-132V AC (nominal 120V AC).
Input delay: 8 milliseconds (on/off).
Conformal coating protects against moisture, dust, and corrosion.
Backplane Current: 120 mA @ 5 volts DC.
Power dissipation: 3.7 watt.
Isolation Voltage: 132V AC (IEC Class 2 Reinforced).
Mounting: DIN rail or panel.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Part Number: 1769-IA16K.
Manufacturer: Allen-Bradley / Rockwell Automation.
Product Type: Digital Input Module.
Input Channels: 16 discrete inputs.
Input Voltage Range: 79–132V AC, nominal 120V AC.
Input Delay (On/Off): 8 ms nominal.
Backplane Current Draw: 120 mA @ 5V DC.
Power Dissipation: 3.7 W.
Isolation Voltage: 132V AC working voltage (IEC Class 2 reinforced insulation).
Conformal Coating: Yes, for enhanced protection against moisture, dust, and corrosion.
Mounting Options: DIN rail or panel mount.
Dimensions: 118 mm × 87 mm × 35 mm.
Operating Temperature Range: 0°C to 60°C (32°F to 140°F).
