CompactLogix 8 Pt 120VAC D/I Iso Module
SKU: 1769-IA8I
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
The 1769-IA8I is a digital input module intended for Allen-Bradley CompactLogix and MicroLogix 1500 systems.
It has 8 individually separated input channels for monitoring 120V AC signals, making it perfect for applications that need electrical separation between inputs.
There are eight digital inputs.
Voltage range is 79-132V AC (nominal 120V AC).
Isolation: Each input is separately isolated.
Input delay: 8 milliseconds (on/off).
Backplane Current: 120 mA @ 5 volts DC.
Power dissipation: 3.7 watt.
Mounting: DIN rail or panel.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Part Number: 1769-IA8I.
Manufacturer: Allen-Bradley / Rockwell Automation.
Product Type: Digital Input Module.
Input Channels: 8 individually isolated inputs.
Input Voltage Range: 79–132V AC.
Frequency Range: 47–63 Hz.
Input Delay: 8 ms nominal (on/off).
Isolation Voltage: 1517V AC or 2145V DC for 1 second.
Working Voltage: 132V AC (IEC Class 2 reinforced insulation).
Backplane Current Draw: 120 mA @ 5V DC.
Power Dissipation: 3.7 W.
Mounting Options: DIN rail or panel mount.
Dimensions: 118 mm × 87 mm × 35 mm.
Operating Temperature Range: 0°C to 60°C (32°F to 140°F).
