CompactLogix 8 Pt 120VAC D/I Iso Module
SKU: 1769-IA8IK
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
The 1769-IA8IK is an 8-point digital input module designed to work with CompactLogix and MicroLogix 1500 systems.
It accepts 120V AC input signals and has separately isolated input channels, which improve noise immunity and allow connection to numerous power sources without interference.
This module is appropriate for industrial control applications requiring electrical isolation between input terminals, such as those involving mixed voltages or sensitive instruments.
It ensures dependable signal detection and system integrity in harsh situations.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Part Number: 1769-IA8IK.
Input Type: Digital (AC voltage sensing).
Number of Inputs: 8 individually isolated channels.
Nominal Input Voltage: 120V AC.
Input Voltage Range: 79–132V AC.
Input Frequency Range: 47–63 Hz.
Input Current: ~10 mA @ 120V AC.
Isolation: Each input channel is individually isolated.
Backplane Current Draw: ~90 mA @ 5.1V DC.
Power Supply Distance Rating: 8 modules.
Mounting: DIN rail or panel mount.
Operating Temperature: 0°C to 60°C (32°F to 140°F).
Certifications: UL, CE, cUL.
Lifecycle Status: Active Mature.
