CompactLogix 8 Pt Analog Input Module

Description: The Allen-Bradley 1769-IF8K is a Compact I/O analogue input module that works with CompactLogix and MicroLogix 1500 controllers. It has eight differential analogue input channels that can accept either voltage or current signals, making it appropriate for a wide range of industrial sensing applications. The "K" suffix on the 1769-IF8K indicates the existence of conformal coating, which distinguishes it from the regular 1769-IF8. This coating adds protection against moisture, dust, and corrosive pollutants, making the module suitable for usage in demanding or high-humidity situations such as water treatment plants, food processing facilities, and outdoor installations. Each input channel supports standard analogue ranges such as ±10V, 0-10V, 0-5V, 1-5V for voltage and 0-20 mA, 4-20 mA for current. The module's 16-bit resolution ensures precise and dependable data gathering. It employs a successive approximation conversion approach and features LED indications for module and channel status, which aids in diagnosis and monitoring. The 1769-IF8K is easy to install on a DIN rail or panel, interfaces effortlessly with CompactLogix controllers via the 1769 backplane, and provides high-speed data interchange for real-time control operations. This module is ideal for applications that require many high-accuracy analogue inputs and increased environmental endurance.
