CompactLogix L19 1MB Ctlr-CC
SKU: 1769-L19ER-BB1BK
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
This controller features 1MB of user memory, embedded digital I/O, and dual Ethernet/IP ports that enable the Device Level Ring (DLR) topology.
It has a 1GB SD card for non-volatile storage and can support up to 8 Ethernet/IP nodes and 8 POINT I/O modules, making it perfect for distributed control systems.
The controller runs on 24V DC and is DIN rail mountable.
Memory: 1MB user memory; 1GB SD card provided.
Embedded I/O:
16 digital inputs (sink type, 24 volt DC).
16 digital outputs (source type: 24 V DC).
Communication:
Dual Ethernet/IP ports with DLR compatibility.
USB programming port.
Expansion Support:
There are up to eight POINT I/O modules.
There are up to eight Ethernet/IP nodes.
Power source: 24V DC.
Mounting: DIN rail.
Buy currently uses Select Automation shop pricing and checkout.
Memory & Processing:
User Memory: 1MB.
Non-volatile Storage: 1GB SD card included (expandable up to 2GB).
Controller Tasks:
Supports up to 32 tasks.
Each task can run up to 100 programs.
Embedded I/O:
Digital Inputs: 16 (24V DC, sink type).
Digital Outputs: 16 (24V DC, source type).
Communication:
EtherNet/IP Ports: 2 (supporting Device Level Ring topology).
USB Port: 1 (for programming and diagnostics).
Supported Ethernet/IP Nodes: Up to 8.
Expansion & Compatibility:
I/O Expansion: Supports up to 8 POINT I/O modules (1734 series).
Programming Software: Studio 5000 Logix Designer.
Mounting: DIN rail.
Power & Environmental:
Power Supply: 24V DC.
Isolation Voltage: 50V continuous (basic insulation), tested at 500V AC for 60 seconds.
Operating Temperature: –20°C to +65°C.
Certifications: UL, CE, C-TICK, KC.
