Compact GuardLogix CPU, L37ERMS, 4M/1.5M
SKU: 1769-L37ERMS
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
The 1769-L37ERMS is a Compact GuardLogix 5370 L3 series safety-enabled programmable automation controller (PAC) that is ideal for applications that require both standard and safety controls.
It provides high-speed motion coordination, reliable communication, and integrated safety features in a small package.
Memory:
4MB standard logic.
1.5MB of safety logic.
Motion Control:
allows for up to 16 CIP motion axes.
Kinematics is included, along with integrated safety functions.
Communication:
Dual EtherNet/IP ports, including Device Level Ring (DLR) capability.
USB programming port.
Expansion:
It supports up to 30 local I/O modules.
There are up to 64 EtherNet/IP nodes.
Storage:
1GB SD card is supplied (expandable up to 2GB).
Certifications:
SIL CL3 (IEC 61508/EN62061).
PLe (En ISO 13849-1).
Buy currently uses Select Automation shop pricing and checkout.
Memory & Processing:
Standard Logic Memory: 4MB.
Safety Logic Memory: 1.5MB.
SD Card: 1GB included (expandable to 2GB).
Controller Tasks: Supports up to 32 tasks, each with up to 100 programs.
Motion & Safety Control:
Motion Axes: Supports up to 16 axes of CIP motion.
Kinematics: Integrated support for robotic motion.
Safety Certifications:
SIL CL3 (IEC 61508 / EN62061).
PLe (EN ISO 13849-1).
Communication:
EtherNet/IP Ports: Dual ports with Device Level Ring (DLR) support.
USB Port: For programming and diagnostics.
EtherNet/IP Nodes: Supports up to 64 nodes.
Expansion & Compatibility:
Local I/O Modules: Supports up to 30 modules.
Programming Software: Studio 5000 Logix Designer.
Mounting: DIN rail.
Power & Environmental:
Power Supply: 24V DC.
Operating Temperature: –20°C to +65°C.
Conformal Coating: Yes, for enhanced environmental resistance.
