Compact GuardLogix CPU, L38ERMS, 5M/1.5M
SKU: 1769-L38ERMS
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
The 1769-L38ERMS is a high-performance, safety-enabled programmable automation controller (PAC) in the Compact GuardLogix 5370 L3 series.
It's intended for demanding industrial applications that require both standard and safety control, integrated motion, and reliable communication.
Memory:
5MB standard logic.
1.5MB of safety logic.
Motion Control:
allows for up to 16 CIP motion axes.
Kinematics is included, along with integrated safety functions.
Communication:
Dual EtherNet/IP ports, including Device Level Ring (DLR) capability.
USB programming port.
Expansion:
It supports up to 30 local I/O modules.
There are up to 80 EtherNet/IP nodes.
Storage:
1GB SD card is supplied (expandable up to 2GB).
Certifications:
SIL CL3 (IEC 61508/EN62061).
PLe (En ISO 13849-1).
Buy currently uses Select Automation shop pricing and checkout.
Memory & Processing:
Standard Logic Memory: 5MB.
Safety Logic Memory: 1.5MB.
SD Card: 1GB included (expandable to 2GB).
Controller Tasks: Supports up to 32 tasks with multiple programs per task.
Motion & Safety Control:
Motion Axes: Supports up to 16 axes of CIP motion.
Kinematics: Integrated support for robotic motion.
Safety Certifications:
SIL CL3 (IEC 61508 / EN62061).
PLe (EN ISO 13849-1).
Communication:
EtherNet/IP Ports: Dual ports with Device Level Ring (DLR) support.
USB Port: For programming and diagnostics.
EtherNet/IP Nodes: Supports up to 80 nodes.
Expansion & Compatibility:
Local I/O Modules: Supports up to 30 modules.
Programming Software: Studio 5000 Logix Designer.
Mounting: DIN rail.
Power & Environmental:
Power Supply: 24V DC.
Operating Temperature: –20°C to +65°C.
