Compact GuardLogix CPU, L38ERMS, 5M/1.5M
SKU: 1769-L38ERMSK
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
The 1769-L38ERMSK is a high-performance, safety-enabled programmable automation controller (PAC) from the Compact GuardLogix 5370 L3 family, specifically developed for harsh industrial settings.
The "K" suffix denotes conformal coating, which provides increased protection against moisture, dust, and corrosive agents—ideal for tough environments such as chemical processing, food preparation, and wastewater treatment.
Memory:
5MB standard logic.
1.5MB of safety logic.
Motion Control:
allows for up to 16 CIP motion axes.
Kinematics is included, along with integrated safety functions.
Communication:
Dual EtherNet/IP ports, including Device Level Ring (DLR) capability.
USB programming port.
Expansion:
There are up to 30 local I/O modules.
It can support up to 80 EtherNet/IP nodes.
Storage:
Includes a 1GB SD card (expandable up to 2GB).
Certifications:
SIL CL3 (IEC 61508/EN62061).
PLe (En ISO 13849-1).
Buy currently uses Select Automation shop pricing and checkout.
Memory & Processing:
Standard Logic Memory: 5MB.
Safety Logic Memory: 1.5MB.
SD Card: 1GB included (expandable to 2GB).
Controller Tasks: Supports multiple tasks and programs for complex automation sequences.
Motion & Safety Control:
Motion Axes: Supports up to 16 axes of CIP motion.
Kinematics: Integrated support for robotic motion profiles.
Safety Certifications:
SIL CL3 (IEC 61508 / EN62061).
PLe (EN ISO 13849-1).
Communication:
EtherNet/IP Ports: Dual ports with Device Level Ring (DLR) support.
USB Port: For programming and diagnostics.
EtherNet/IP Nodes: Supports up to 80 nodes.
Expansion & Compatibility:
Local I/O Modules: Supports up to 30 modules.
Programming Software: Studio 5000 Logix Designer.
Mounting: DIN rail or on-machine installation.
Environmental & Durability:
Conformal Coating: Yes (indicated by “K” suffix) for enhanced protection against moisture, dust, and corrosive agents.
Power Supply: 24V DC.
Operating Temperature: –20°C to +65°C.
