CompactLogix 16 Pt D/O Relay Module

Description: The Allen-Bradley 1769-OW16K is a ruggedized variant of the normal 1769-OW16 relay output module from the Compact I/O 1769 series. It is compatible with CompactLogix and MicroLogix 1500 controllers and has 16 relay outputs, each of which is separately separated for more flexible wiring and protection. The "K" suffix denotes the existence of conformal coating, which shields the module's internal circuitry from moisture, dust, and corrosives. This makes it perfect for usage in maritime, chemical, food processing, and other harsh industrial settings. Each output incorporates a mechanical relay contact (Form A, SPST-NO) that can switch both AC (10-250V) and DC (5-125V) loads. The module can handle resistive loads of up to 2.5 A per channel and incorporates diagnostic status LEDs. It is simple to install on a DIN rail or panel and works smoothly with other I/O modules. This module is appropriate for industrial control systems that require reliable switching of mixed AC/DC loads, particularly in severe or corrosive environments.
