Clamping cartridge, KP-25-5000
SKU: 178460
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Specifications
• Clamping cartridges KP
• Mounting position optional
• Type of clamping with direction of action on both sides, Clamping via spring force, released via compressed air
• Design Tilting wedge mechanism
• Variants Piston rod at one end
• Operating pressure ≤1 MPa
• Operating pressure ≤10 bar
• Release pressure ≥0.3 MPa
• Release pressure ≥3 bar
• Round material to be clamped 25 mm
• Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Buy currently uses Select Automation shop pricing and checkout.
Clamping cartridges KP
• For in-house construction of clamping units.
• Not certified for use in safety-oriented controllers
• For in-house assembly of clamping units
• Not certified for use in safety-related control systems
