Mini guided drive, DFC-6-5-P-A-KF

Specifications • Mini guided drives DFC • Distance from centre of gravity of load to yoke plate xs 10 mm • Stroke 5 mm • Piston diameter 6 mm • Operating mode, drive unit Yoke • Cushioning Elastic cushioning rings/plates at both ends • Mounting position optional • Guide Recirculating ball bearing guide • Design Guidance • Position detection Via proximity switch • Symbol 00991737 • Operating pressure 0.15 MPa ... 1 MPa • Operating pressure 1.5 bar ... 10 bar • Max. speed 1 m/s • Theoretical force at 0.6 MPa (6 bar, 87 psi), advance stroke 17 N
