Vacuum generator, VAD-3/8
SKU: 19294
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Specifications
• Vacuum generators VAD/VAK
• Nominal size, Laval nozzle 1.5 mm
• Mounting position optional
• Ejector characteristic High vacuum
• Design T-shape
• Symbol 00991482
• Operating pressure 0.15 MPa ... 1 MPa
• Operating pressure 1.5 bar ... 10 bar
• Operating pressure 21.75 psi ... 145 psi
• Max. vacuum 80 %
• Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Buy currently uses Select Automation shop pricing and checkout.
Vacuum generator VAD, VAK
• Sturdy aluminium housing for direct connection of a suction cup
