Solenoid valve, MHP1-M4H-2/2G-M3-HC
SKU: 197045
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Specifications
• Solenoid valves MH1, semi in-line valve
• Valve function 2/2-way, closed, monostable
• Type of actuation Electric
• Construction width 10 mm
• Standard nominal flow rate (standardised to DIN 1343) 14 l/min
• Pneumatic working port M3
• Operating voltage 5V DC
• Operating pressure -0.09 MPa ... 0.2 MPa
• Operating pressure -0.9 bar ... 2 bar
• Operating pressure -13.05 psi ... 29 psi
• Design Poppet valve with spring return
• Type of reset Mechanical spring
• Pneumatic connection, port 1 Sub-base
Buy currently uses Select Automation shop pricing and checkout.
Solenoid valve MHA1, MHP1
• Small, fast and versatile and long-lasting: the compact miniature valve can actuate many tightly spaced channels or cylinders.
• Optional: compact electronics module with holding current reduction.
• Directly actuated poppet valve
• Miniature valve: grid dimension 10 mm
• Switching times down to 4 ms
• Sub-base valve
• Manifold block for 2 ... 10 valves
• Use as a pilot valve
• UL certification; same connections and cables as for the VUVG
