20 SERIES 3 STEP MODULAR RELAY 12VDC
SKU: 202690120000
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Step relays that are modular:
Twenty modular step relays in sequence.
1NO + 1NC coils for AC and DC.
Test and manual override buttons.
One hour is the maximum pulse duration. One module is compact (17.5 mm broad).
Mechanical contact position flag indicators.
Buy currently uses Select Automation shop pricing and checkout.
SERIES 20:
SWITCH CURRENT: 16A.
NUMBER OF STEPS: 3 steps.
DESCRIPTION: Modular pulse step relay.
CONTACT CONFIGURATION: 2 contacts.
COIL VOLTAGE: 12 VDC.
MOUNTING: Modular DIN rail mount.
DIMENSIONS (MM): (H) 84 x (W) 17.5 x (D) 57.
