25A 3NO+1NC CONTACTOR 230VAC/DC
SKU: 223402304740
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
22 modular contactors in series:
Auto-Off/Auto-On selector.
Constant duty coils and contacts.
AC/DC silent coil (protected by varistor).
LED indicators and a mechanical flag are standard.
Auxiliary contact module that can be clipped on (1NO+1NC or 2NO).
Strengthened insulation serving as a protective barrier between the coil and the contacts.
Buy currently uses Select Automation shop pricing and checkout.
Series 22:
Rated power ac-1 (a): 25a
Rated power ac-3 kw (230v): 1.0 kw (single phase motor rating)
Number of poles: 4
Description: modular contactor
Mounting: modular din rail mount
Modules width in 17.5 mm: 2
Contact configuration: 3no + 1nc.
Coil voltage ac/dc: 230v.
Dimensions (mm): (h) 89 x (w) 35 x (d) 61
