2 POLES 32A O-I-II 4 CONTACT SWITCH
SKU: 227631
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Series of PR-ONE cam switches:
Key aspects include:
Switching angle of 45°.
Two-way switches have the option to be turned off.
Contacts were opened forcibly.
Meets load break criteria up to 690 volts.
Front protection is IP40, with an IP20 rear terminal (finger protection).
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
SERIES: PR ONE.
CONTACT RATING AC-21: 32A.
CONTACT RATING AC-23: 11 KW.
NUMBER OF POLES: 2 pole.
DESCRIPTION: 2-way rotary cam switch.
ACTION: (O-I-II).
OPERATING TEMPERATURE: -20°C to 70°C.
FRONT BEZEL: 48 mm - engraved aluminium plate with black handle.
STANDARDS OF COMFORMITY: IEC EN 60947-1, 60947-3, UL508, UL-CSA.
