3 POLES 32A O-I-II 6 CONTACT SWITCH
SKU: 227632
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Series of PR-ONE cam switches:
Key details:
45-degree angle switch-over.
Two-way switches have the option to be turned off.
Contacts that were forced to open.
Meets the criteria for load breaks up to 690V.
Finger protection at the IP20 rear terminal and front protection at IP40.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
SERIES: PR ONE.
CONTACT RATING AC-21: 32A.
CONTACT RATING AC-23: 11 KW.
NUMBER OF POLES: 3 poles.
DESCRIPTION: 2-way rotary cam switch.
ACTION: (O-I-II).
OPERATING TEMPERATURE: -20°C to 70°C.
FRONT BEZEL: 48 mm - engraved aluminium plate with black handle.
STANDARDS OF COMFORMITY: IEC EN 60947-1, 60947-3, UL508, UL-CSA.
