Proximity sensor, SDBT-BSW-1L-NU-W-0.3-N-M12
SKU: 2427615
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Specifications
• Hinge cylinders DW
• Accessories, Proximity switch for T-slot, magneto-resistive
• Electrical connection 1, connector system M12x1, A-coded to EN 61076-2-101
• Operational voltage range DC 10 V - 30 V
• Switching element function N/O contact
• Switching output NPN
• Measured variable Position
• Measuring principle Magneto-resistive
• Ambient temperature -25 °C ... 85 °C
• Max. travel speed 1 m/s
• Repetition accuracy 0.2 mm
• Switching behavior during welding process Output signal freezes
Buy currently uses Select Automation shop pricing and checkout.
Proximity switch SDBT-BSW
• Electronic proximity switch for T-slot, can be inserted from above, welding field resistant 50-60Hz AC and 1000Hz MFDC.
• Measuring principle: magneto-resistive
• Welding field immune
• Resistant to welding spatter
• For contactless piston rod position sensing on Festo pneumatic cylinders, especially the hinge cylinders DW/DWA/DWB/DWC for the automotive and tier 1 supplier industry
• Insertable in the slot from above, screw-clamped
• LED switching status indication
• Cable length 0.3 ... 5 m
