ArmorView Plus 7 Graphic Terminal
SKU: 2711P-T12W22D9P-BM001
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
The 2711P-T12W22D9P-BM001 ArmorView Plus 7 Graphic Terminal is the most basic configuration in the ArmorView Plus 7 family, intended for tough, on-machine industrial applications.
For users that want the most flexibility in creating their own operator interface layout from the ground up, this terminal is perfect.
Buy currently uses Select Automation shop pricing and checkout.
Display & Interface:
Screen Size: 12.1-inch widescreen colour touch display.
Resolution: 1280 x 800 (WXGA).
Touchscreen Type: Capacitive.
Operating System: Windows 10 IoT Core.
Performance & Power:
Model Type: Performance model.
Power Input: 24V DC (range: 18–30V DC).
Branding: Brandless configuration for OEM flexibility.
Connectivity & I/O:
Ethernet: Dual ports supporting DLR, linear, and star topologies.
I/O Configuration: Ethernet I/O with 7 blank button positions for full customization.
USB Ports: Available for peripherals and data access.
Design & Mounting:
Enclosure: Cast-aluminium housing with IP66 rating.
Mounting Options: Arm mount adapter included compatible with pedestal or VESA mounts.
Button Plate: Blank configuration—no pre-installed buttons or switches.
Software & Functionality:
FactoryTalk® View ME: For application development and runtime visualization.
Remote Access: VNC and FactoryTalk ViewPoint support.
File Viewer: Built-in support for PDFs and manuals.
