ArmorView Plus 7 Graphic Terminal
SKU: 2711P-T12W22D9P-BM002
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
The 2711P-T12W22D9P-BM002 ArmorView Plus 7 Graphic Terminal is a tough, high-performance operator interface intended for industrial use.
This terminal is appropriate for applications that require reliable visualization and control directly on the machine.
If you're creating a control station or upgrading an HMI, this model provides both versatility and durability.
Buy currently uses Select Automation shop pricing and checkout.
Specifications:
Display: 12.1-inch widescreen TFT with 1280 x 800 WXGA resolution and 18-bit colour graphics.
Touchscreen: Capacitive touch interface for intuitive operation.
Operating System: Windows 10 IoT Core.
Power Supply: 24V DC input (range 18–30V DC).
Connectivity:
Dual Ethernet ports supporting Device Level Ring (DLR), linear, or star topologies.
USB ports for peripheral connections.
Model Type: Performance model, designed for on-machine use.
I/O Configuration: Includes Ethernet I/O with 7 blank positions for customization.
Design & Mounting:
Enclosure: Cast-aluminium housing with IP66-rated front panel for harsh environments.
Mounting Options: Arm mount, pedestal, or VESA-compatible bracket.
Button Plate: Blank configuration, allowing for user-defined button layouts and accessories.
Software & Functionality:
FactoryTalk® View Machine Edition: Used for application development and configuration.
Remote Monitoring: Supports VNC and FactoryTalk ViewPoint for remote access.
File Viewer & PDF Support: Enables viewing of manuals and guides directly on the terminal.
