ArmorView Plus 7 Graphic Terminal
SKU: 2711P-T12W22D9P-BM013
Out of stock
Availability: Out of Stock
Marketplace sellers
Submit a quote request to receive offers from sellers of this product.
Short Description
Description:
ArmorView Plus 7 Graphic Terminal is a high-performance industrial HMI designed for rugged on-machine applications.
It builds on previous models, with a more filled button plate and improved control capabilities.
This setup is appropriate for procedures that require several control inputs and good visibility.
Buy currently uses Select Automation shop pricing and checkout.
Core Features:
Display: 12.1-inch wide-aspect ratio TFT color touchscreen.
Operating System: Windows 10 IoT Core.
Power Supply: 18–30V DC.
Connectivity: Dual-port Ethernet with Device Level Ring (DLR).
Model Type: Performance model for demanding environments.
Button Plate Configuration:
Positions 0–5: Momentary push buttons.
Position 6: Emergency stop (ESTOP) with legend button.
Ethernet I/O: Integrated ArmorBlock® Dual Port EtherNet/IP module for button interface.
Installation & Safety Highlights:
Designed for on-machine mounting with arm, pedestal, or VESA options.
Includes FactoryTalk View ME software for HMI development.
Features sealed gaskets and grounding pads for ingress protection and EMC compliance.
Contains a sealed lithium battery—requires proper handling and disposal.
